Analog Output Module | PM152 3BSE003643R1 | ABB

Technical Specifications

ABB PM152 3BSE003643R1 Analog Output Module belongs to ABB Advant OCS series distributed control system spare parts, This dedicated analog output module is tailor-made for Advant OCS DCS rack control system, serving as the core analog signal driving unit inside the control cabinet. It receives digital operation instructions transmitted by the main controller, converts internal digital bus signals into standard continuous analog current and voltage signals, and outputs driving signals to on-site actuators such as regulating valves, frequency converters and positioners to realize closed-loop adjustment of industrial production parameters.

Request a Quote Now | Email ：info@amikon.cn

Troubleshooting & Comissioning Checklist

Visual Integrity: Check the module, backplane interface, and edge connectors for cracked solder, missing components, or transport damage.
Backplane Inspection: Clean dust, debris, and corrosion off the housing rack pins to guarantee clean electrical connections.
Grounding Compliance: Confirm that the subrack or DIN rail installation is securely bonded to the central cabinet earth system to eliminate stray EMF/RFI.

Field Engineering Considerations

Channel Isolation: The PM152 features independent channel isolation. Engineers must maintain this isolation during cabinet wiring by avoiding shared return paths, which prevents ground loops from corrupting critical 4-20mA or voltage control signals.
Overload & Protection: The module includes built-in overload protection. However, inductive field loads can cause inductive voltage spikes. Ensure external surge suppression or flyback diodes are installed at the actuator side if needed.
Signal Type Matching: Configure each channel accurately for voltage or current loop outputs in the Freelance engineering software before connecting field devices to prevent over-current damage to analog positioners.

Can't Find the Part? - Whatsapp +86 1802776786 for Assistance

Technical FAQ

Q: What is the core function of the PM152 module?
A: The module converts digital control signals received from the controller into standard analog output signals (either voltage or current). These signals directly drive on-site actuators, valves, and other regulating process instruments.

A: It communicates with the central controller unit via the S800 bus architecture. It is primarily integrated into the ABB AC800F Freelance system and legacy Advant Controller configurations.

A: The ABB PM151 is strictly an Analog Input module used to collect sensor readings. The PM152 is strictly an Analog Output module used to push commands to equipment. The ABB PM153 is a hybrid layout that integrates both input loops and output loops on a single card.

Q: Do you supply brand-new, original parts or second-hand refurbished items?

A: Our stock consists of Original New items; all products undergo quality inspection to ensure they are fully functional.

Q: What guarantees are included with the shipment?
A: All items in stock are tested by engineers, packed in professional ESD packaging, and shipped via express logistics with a global delivery time of 24–48 hours.

Q: How long does global shipping take?
A: Stock items are typically dispatched within 24 hours. Shipments are sent via DHL or FedEx Express, taking approximately 3–5 days to reach Asia, 4–6 days to Europe and the Middle East, and usually arriving within a week in major industrial regions worldwide.

Q: If the model I need is not listed on the website, can I request a quote?
A: Yes. We hold over 200,000 SKUs of industrial spare parts in stock, and many long-tail models are not listed in full. You can send us an RFQ (Request for Quote) directly, and we will provide wholesale pricing promptly.
