DSDP170
Pulse Counting Board · 57160001-ADF · S100 I/O
Lifecycle note: Record encoder wiring, count direction, engineering-unit scaling and reference positions before replacing the pulse counting board.
ItemNO:
57160001-ADFProduct Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales17@amikon.cnWhatsapp/Mob:
+86 153 5940 8275Pulse Counting Board · S100 I/O
ABB DSDP170 is an ABB S100 I/O pulse counting board for positioning, length measurement, speed and frequency measurement. Order 57160001-ADF identifies the DSDP170 board; ABB publishes a maximum pulse frequency of 2.5 MHz.
The S100 I/O system overview describes four position-transducer interfaces with A, B and STROBE inputs. Confirm the encoder output format and the installed termination arrangement before connecting field signals. The board has a published net weight of 0.38 kg and dimensions of 328.5 × 238.5 × 18 mm (depth × width × height).
A replacement should retain the project pulse-counting mode, direction convention and mechanical reference. Test known motion and speed against the controller indication under the approved commissioning procedure. Procurement should identify the board separately from DSDP170 encoder kits and retain nameplate and revision photographs.
| Manufacturer | ABB |
|---|---|
| Model / order number | DSDP170 / 57160001-ADF |
| Product type | Pulse counting board |
| I/O family | S100 I/O |
| Primary measurements | Position / length and speed / frequency |
| Transducer interfaces | 4 |
| Pulse inputs per transducer | A, B and STROBE |
| Maximum pulse frequency | 2.5 MHz |
| Net depth / length | 328.5 mm |
| Net width | 238.5 mm |
| Net height | 18 mm |
| Net weight | 0.38 kg |
| Associated encoder kits | DSDP170K01: 5730032-DV; DSDP170K02: 3BSE019925R1 |
| Customs tariff number | 85389091 |
Record encoder wiring, count direction, engineering-unit scaling and reference positions before replacing the pulse counting board.
ABB describes four position-transducer interfaces. Each has A, B and STROBE pulse inputs; count transducers separately from the individual signal wires when planning the installation.
It is the maximum pulse frequency stated by ABB for the DSDP170. It is not a controller scan-rate or mechanical speed rating; convert encoder pulses per revolution and shaft speed before checking the application.
The application depends on the relationship between encoder signals and the configured direction convention. Commissioning should compare positive and negative commanded motion with the reported position before releasing the axis.
The strobe signal is part of the documented transducer interface. Preserve its wiring and the installed project function so that a captured reference or measured position is associated with the intended event.
No. ABB lists 57160001-ADF for the board and 3BSE019925R1 for the DSDP170K02 pulse encoder input kit. State the required scope separately and check the delivered parts against the purchase order.
No. Encoder resolution, mechanical conversion, controller configuration and the application cycle also affect the result. Validate position and speed performance in the installed system rather than deriving it from the board frequency limit alone.
Record the reference position, engineering-unit conversion and any application-specific count offset. Re-establish the reference using the approved machine procedure before trusting absolute displayed position.
Compare the exact order number, connector arrangement and hardware revision with the installed unit. The ABB catalog dimensions are 328.5 mm deep, 238.5 mm wide and 18 mm high, with a net weight of 0.38 kg; these are identification checks, not a substitute for functional testing.
Send the model, complete part number, quantity, destination and nameplate photo. We will verify identification details before confirming availability and lead time.
Official PDF extract: DSDP170 / 57160001-ADF — Sales PLC Cover & ABB Documentation. File size is below 1 MB; verify the exact installed hardware and configuration before use.
