IMHSS03
Hydraulic Servo Module · Valve Position Control · Turbine Control · LVDT Feedback · Single MMU Slot
Lifecycle note: Confirm the complete installed ABB configuration before replacement or migration.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
info@amikon.cnWhatsapp/Mob:
+86 18020776786Hydraulic Servo Module · Harmony Rack Turbine Control
ABB IMHSS03 is a Hydraulic Servo module for Harmony Rack turbine-control applications. ABB describes it as a valve-position-control module that provides an interface through which a Harmony controller can drive a servo valve or I/H converter for manual or automatic control of a hydraulic actuator. The controller uses function code 55 or 150 to configure and access the module’s input and output channels. Selection should be based on the complete model designation and the confirmed role in the installed ABB system, not on a shortened name, product appearance or an assumed equivalent.
ABB lists typical uses including steam-turbine throttle and control valves, gas-turbine fuel valves, inlet guide vanes and nozzle angle. The module regulates current to the servo valve and receives actuator-position feedback from a linear variable differential transformer (LVDT). ABB describes IMHSS03 as an intelligent I/O module with onboard microprocessor, memory and communication circuitry; it commonly works with the IMFCS01 Frequency Counter module. Correct installation requires review of the actual turbine-control design, termination unit, jumper and switch configuration, wiring, controller application and safety procedure. A quotation request should include the required quantity, destination, a clear nameplate photograph and the relevant installed-configuration evidence so the exact requirement can be reviewed before order confirmation.
| Manufacturer | ABB |
|---|---|
| Model | IMHSS03 |
| Product family | Harmony Rack Turbine Control |
| Product type | Hydraulic Servo module |
| Primary function | Valve position control |
| Controller configuration | Function code 55 or 150 |
| Actuator interface | Drives a servo valve or I/H converter |
| Control mode | Manual or automatic hydraulic-actuator control |
| Position feedback | LVDT |
| Typical applications | Steam turbine throttle/control valves; gas turbine fuel valves; inlet guide vanes; nozzle angle |
| Module architecture | Intelligent I/O module with onboard microprocessor, memory and communication circuitry |
| Associated module | Typically works with IMFCS01 Frequency Counter module |
| Mounting | One slot in a module mounting unit |
| Field connection | Cable to termination unit; field wiring on the termination unit |
| Configuration | PCB jumpers/switches and termination-unit jumpers/dipshunts configure the module and I/O channels |
Confirm the complete installed configuration before replacement or migration.
ABB identifies IMHSS03 as a Hydraulic Servo module for Harmony Rack turbine-control applications.
It is a valve-position-control module through which a Harmony controller can drive a servo valve or I/H converter for manual or automatic hydraulic-actuator control.
ABB specifies function code 55 or 150 for configuring and accessing the module input and output channels.
Compatibility depends on the actual Harmony controller configuration, termination unit, servo interface, LVDT feedback arrangement, wiring and application program. Verify all of these before replacement.
ABB lists steam-turbine throttle/control valves, gas-turbine fuel valves, inlet guide vanes and nozzle-angle applications.
ABB specifies one module-mounting-unit slot, a cable to the termination unit and field wiring on the termination unit. Follow the applicable ABB procedure and approved turbine-control safety steps.
This listing is marked In Stock. Confirm the required quantity, the exact model and the expected dispatch date against the current warehouse record before quotation.
The fixed procurement status for this listing states Original New with One Year Warranty. The quotation should confirm the offered condition and the applicable warranty terms.
The item should be inspected and protected against moisture, static electricity and impact before shipment. Confirm the dispatch date, carrier, destination and any customer shipping-account instruction for the actual order.
Send the model, complete part number, quantity, destination and nameplate photo. We will verify identification details before confirming availability and lead time.
Technical information is based on ABB Harmony Rack Turbine Control Data Sheet. Final suitability must be verified against the exact installed unit and official documentation.
