Woodward 5441-693 High-Density Discrete I/O Field Termination Module
5441-693
High-Density Discrete I/O Field Termination Module · 24-Input / 12-Output Discrete I/O FTM for Woodward MicroNet and 505DE Control Hardware
Lifecycle note: Use the unit nameplate and current Woodward documentation as final references before approving a replacement.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales17@amikon.cnWhatsapp/Mob:
+86 15359408275High-Density Discrete I/O Field Termination Module · Woodward MicroNet and 505DE Control Hardware
Woodward 5441-693 is a high-density discrete I/O field termination module documented with 24 inputs and 12 outputs. Woodward manual 26361V1 lists the FTM as a component in 505DE control kits, where it terminates cabinet field wiring for the associated discrete I/O electronics.
Woodward 5441-693 provides an organized interface between external switches, contacts and controlled devices and the compatible MicroNet or 505DE I/O subsystem. The FTM is a termination component; signal processing and application logic reside in the matched controller and I/O modules.
The official 505DE bill of material references two Woodward 5441-693 modules at E/C revision B in kits 8262-1040 and 8262-1041. Actual channel allocation, field voltage, commons, cable assemblies and output loads depend on the installed cabinet drawings.
Before replacement, label every conductor and cable, isolate all field energy, compare connector keying and revision, and verify 24-input/12-output mapping against the cabinet schematic. Continuity, isolation and point-to-point I/O tests are required before returning Woodward 5441-693 to service.
| Manufacturer | Woodward |
|---|---|
| Model | 5441-693 |
| Product type | 24-Input / 12-Output Discrete I/O FTM |
| System family | Woodward MicroNet and 505DE Control Hardware |
| Module function | High-density discrete I/O field termination |
| Discrete inputs | 24 |
| Discrete outputs | 12 |
| Official assembly reference | 505DE kits 8262-1040 and 8262-1041 |
| Documented component revision | E/C revision B in listed kits |
| Installed-system context | MicroNet / 505DE control cabinet |
Use the installed-unit nameplate, current Woodward documentation and approved site engineering records as the final references.
Woodward manual 26361V1 identifies Woodward 5441-693 as a high-density discrete I/O FTM with 24 inputs and 12 outputs. The field-voltage level, commons, channel assignments and output loads must be taken from the installed cabinet drawings.
Woodward 5441-693 is documented as a component in Woodward 505DE kits 8262-1040 and 8262-1041 and interfaces field wiring with compatible MicroNet discrete I/O electronics. Confirm the exact cabinet architecture and cable set before application.
Woodward 5441-693 is a field termination module rather than the controller executing application logic. The matched I/O electronics and MicroNet or 505DE application process the discrete states and commands connected through the FTM.
Before removing Woodward 5441-693, isolate field energy and record every terminal, wire number, cable, jumper, shield and common connection. Photograph the assembly and compare the 24-input/12-output allocation with the current cabinet schematic.
Mount Woodward 5441-693 in the designated location, verify mechanical security and connector keying, then reconnect labeled field wiring to the approved terminals. Perform continuity, insulation and point-to-point input/output tests before enabling controlled equipment.
Official 505DE kit lists show Woodward 5441-693 at E/C revision B. Compare the installed revision, connector arrangement, terminal labeling and matched I/O module documentation; do not infer interchangeability solely from the base part number.
A direct substitution requires the same channel count, terminal arrangement, connector keying, cable compatibility, field voltage, commons and matched I/O electronics. Verify those items and the application drawings before replacing Woodward 5441-693 with another FTM.
Provide Woodward 5441-693, the E/C revision, cabinet or kit number, associated I/O module, cable part numbers, field voltage, connector and terminal photographs, and the 24-input/12-output wiring schedule to verify the replacement.
Woodward 505DE manual 26361V1 lists Woodward 5441-693 in the official kit bills of material and describes the module as an HD discrete I/O FTM with 24 inputs and 12 outputs. Site schematics define the exact channel use.
Send the complete model, part number, revision, quantity, destination and nameplate photo. We will verify identification details before confirming availability and lead time.
