High Performance Coupling Module|87TS01I-E GJR2368900R2550 | ABB

Technical Specifications

The ABB 87TS01I-E GJR2368900R2550 coupling module is engineered to provide robust and efficient data transmission in harsh industrial environments. With its advanced design, it ensures seamless integration into existing automation systems, facilitating smoother operation and maintenance.Crafted from high-grade materials for durability and reliability, this module boasts an impressive lifespan under challenging conditions, reducing downtime and maintenance costs.Operated within a temperature range of -20°C to +60°C, this module can withstand extreme environmental conditions, making it suitable for applications in various industries including manufacturing, mining, and process control.

Request a Quote Now | Email ：info@amikon.cn

Troubleshooting & Comissioning Checklist

Power Supply Redundancy: Verify the presence of a redundant 24V module supply line.
Battery-Buffer Check: Ensure the internal battery is fresh and properly engaged to safeguard the module’s 8 MB RAM and parity checking functionality during power disruptions.
Bus Configuration Checking: Confirm that the module's target station address matches the system's database configuration.

Field Engineering Considerations

Grounding Requirements: To eliminate ground loops across distributed computer systems, ensure that the communication cable shielding is grounded effectively according to Procontrol P system standards.
Distance Considerations: Field wiring for RS-232C links should remain within a 15-meter threshold to prevent signal degradation. For longer distances extending into the field, configure the interface for RS-422 differential signaling and utilize high-quality shielded twisted-pair cables.
Engineering Action: During DCS network configuration, program the diagnostic scanning intervals on external workstations so that they do not exceed these transmission thresholds. Overloading the buffers will lead to data collision or dropped data packets on the station bus.

Can't Find the Part? - Whatsapp +86 1802776786 for Assistance

Technical FAQ

Q: What is the primary function of the 87TS01I-E module?
A: The module serves as a process interface coupling device. It allows external host computers, Process Operator Stations (POS), Programming, Diagnosis and Display Systems (PDDS), or Control Diagnosis Stations (CDS) to communicate bidirectionally with the broader PROCONTROL system bus.

A: The front faceplate contains dedicated status LEDs. These illuminate to display real-time operational states, data transmission activity, and system or module-level disturbances (faults).

A: The card utilizes a standard interface for seamless hookup to the internal PROCONTROL station bus. For external communication with host machines or configuration terminals, it natively provides a serial RS-232C interface executing a dedicated transmission protocol.

Q: Do you supply brand-new, original parts or second-hand refurbished items?

A: Our stock consists of Original New items; all products undergo quality inspection to ensure they are fully functional.

Q: What guarantees are included with the shipment?
A: All items in stock are tested by engineers, packed in professional ESD packaging, and shipped via express logistics with a global delivery time of 24–48 hours.

Q: How long does global shipping take?
A: Stock items are typically dispatched within 24 hours. Shipments are sent via DHL or FedEx Express, taking approximately 3–5 days to reach Asia, 4–6 days to Europe and the Middle East, and usually arriving within a week in major industrial regions worldwide.

Q: If the model I need is not listed on the website, can I request a quote?
A: Yes. We hold over 200,000 SKUs of industrial spare parts in stock, and many long-tail models are not listed in full. You can send us an RFQ (Request for Quote) directly, and we will provide wholesale pricing promptly.
