Woodward 5501-367 48-Input 24-Output Discrete I/O Field Termination Module
5501-367
48-Input 24-Output Discrete I/O Field Termination Module · High-Density Discrete I/O Field Termination Module for Woodward MicroNet Simplex I/O System
Lifecycle note: Use the unit nameplate and current Woodward documentation as final references before approving a replacement.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales17@amikon.cnWhatsapp/Mob:
+86 1535940827548-Input 24-Output Discrete I/O Field Termination Module · Woodward MicroNet Simplex I/O System
Woodward 5501-367 is a Simplex high-density discrete I/O field termination module documented in Woodward Industrial Products Catalog 25182. The module provides the field-side termination arrangement for 48 discrete inputs and 24 discrete outputs in compatible MicroNet control-system configurations.
The official catalog identifies the 48 inputs of Woodward 5501-367 as 24 Vdc discrete inputs. Its 24 discrete outputs are routed from connectors J1 and J2 to J3, so connector assignment and the two-cable arrangement must follow the documented module and cabinet wiring.
Woodward lists 5501-367 as the low-voltage FTM option associated with compatible Simplex discrete I/O hardware such as the 5466-1050 configuration. The installed main I/O module, coder or software compatibility and cable selection must be confirmed from the actual system bill of materials.
Before replacing Woodward 5501-367, isolate field power and compare connector keys, input voltage, output routing, cable numbers, terminal schedule, grounding and revision markings. Point-to-point verification and functional testing are required before returning the discrete I/O channels to automatic service.
| Manufacturer | Woodward |
|---|---|
| Model | 5501-367 |
| Product type | High-Density Discrete I/O Field Termination Module |
| System family | Woodward MicroNet Simplex I/O System |
| Module type | Simplex high-density discrete I/O field termination module |
| Discrete inputs | 48 inputs, 24 Vdc |
| Discrete outputs | 24 outputs |
| Connector routing | Discrete outputs routed from J1 and J2 to J3 |
| Documented system role | Low-voltage FTM option for compatible Simplex discrete I/O |
| Associated module reference | 5466-1050 or compatible documented spare configuration |
| Cable requirement | Two cables per the official catalog selection table |
| Ordering check | Complete model, revision, connector and installed module configuration |
Use the installed-unit nameplate, current Woodward documentation and approved site engineering records as the final references.
Woodward 5501-367 is documented as a Simplex high-density discrete I/O field termination module with 48 discrete inputs and 24 discrete outputs. The catalog identifies the inputs as 24 Vdc and specifies output routing through its connectors.
The Woodward catalog states that the 24 discrete outputs on Woodward 5501-367 are routed from J1 and J2 to J3. Replacement work must preserve the exact connector mapping, cable identification and terminal schedule used by the installed cabinet.
Woodward 5501-367 is listed as the low-voltage field-termination option for compatible Simplex discrete I/O configurations, including documented association with 5466-1050 hardware. Verify the installed module, software compatibility and bill of materials before use.
Woodward catalog 25182 references two cables for the compatible Simplex discrete I/O arrangement using Woodward 5501-367. Select cables from the applicable official table and confirm connector keys, length, shielding and cabinet routing against site drawings.
Install Woodward 5501-367 with field and control power isolated. Confirm mounting, grounding, 24 Vdc input circuits, J1/J2/J3 assignments, cable strain relief and terminal labeling, then perform point-to-point checks before connecting the main I/O module.
Commission Woodward 5501-367 by verifying every input indication and commanded output against the approved cause-and-effect or I/O list. Test field voltage, polarity, channel mapping, de-energized states and fail-safe behavior before restoring automatic operation.
No direct substitution should be assumed. Woodward 5501-367 is the documented low-voltage 48-input/24-output Simplex FTM. Compare input voltage, output routing, connector arrangement, cable set, revision and supported main I/O hardware before replacement.
Order Woodward 5501-367 using the complete part number, revision, serial or date code, installed main I/O module, cable numbers, 24 Vdc field-voltage confirmation, connector photographs and cabinet drawings to verify the exact Simplex configuration.
Woodward Industrial Products Catalog 25182 explicitly lists Woodward 5501-367 as a 48-input, 24-output discrete I/O field termination module, describes 24 Vdc inputs and J1/J2-to-J3 output routing, and provides the associated selection references.
Send the complete model, part number, revision, quantity, destination and nameplate photo. We will verify identification details before confirming availability and lead time.
