190214-01 Bently Nevada 3500/94M Normal I/O Module
190214-01
190214-01 is the Bently Nevada 3500/94M Normal I/O module identified in Baker Hughes datasheet 122M3217 Rev. N. 190214-01 occupies the rear rack position associated with a 3500/94M VGA main module and provides the normal I/O side of a configured display path. 190214-01 is not the 184826-01 main module, is not the 190214-02 power-only I/O module, and does not include a touch display, TDI module, display cable, rack, or complete 3500/94M system.
Scope note: 190214-01 is a rear I/O component. 190214-01 is not the 184826-01 front main module and does not by itself display rack information or constitute a complete 3500/94M system.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales1@amikon.cnWhatsapp/Mob:
+86 18150117685Official exact-spare identity with front module, rear I/O and complete display-system boundaries kept separate.
Baker Hughes datasheet 122M3217 Rev. N lists 190214-01 exactly as the 3500/94M Normal I/O module. The nearby 190214-02 entry is a different power-only I/O module for the front-mount display option.
190214-01 is a rear I/O component. 190214-01 is not the 184826-01 front main module and does not by itself display rack information or constitute a complete 3500/94M system.
A complete matched 3500/94M display path requires a front VGA module, an associated I/O module, a supported touch display and cables, a compatible rack with the required 3500/22 TDI, and the applicable firmware and software configuration.
| Part number | 190214-01 |
|---|---|
| Full model | 3500/94M 190214-01 |
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Product family | 3500/94M VGA Display Monitor |
| Official spare identity | 3500/94M Normal I/O module |
| Component class | Rear I/O module |
| Rack position | 1 full-height rear slot |
| Dimensions | 241.3 x 24.4 x 99.1 mm (9.50 x 0.96 x 3.90 in) |
| Weight | 0.34 kg (0.75 lb) |
| Associated front component | 3500/94M VGA main module; 184826-01 is the separately identified main-module spare |
| Display boundary | Touch display, display cables, and mounting hardware are not identified as included with the bare 190214-01 spare |
| Variant boundary | 190214-01 is the Normal I/O module; 190214-02 is the different power-only I/O module for the front-mount display |
| System hardware requirement | A configured 3500/94M system requires a 3500/22 TDI module |
| Approval boundary | Do not assign a hazardous-area approval to bare 190214-01 without the configured system order option and applicable certification evidence |
| Official source | Baker Hughes / Bently Nevada datasheet 122M3217 Rev. N |
| Complete-system Required matched components | A complete matched 3500/94M display path combines 190214-01 with the correct front VGA module, supported display, cables, 3500/22 TDI, rack, firmware, and software configuration. |
| Complete-system Display functions | System event lists, alarm event lists, module and channel data, alarm and OK status, and custom screens are functions of the complete matched 3500/94M path, not of bare 190214-01 alone. |
| Complete-system Power and environmental values | The datasheet states power and environmental limits for the complete matched 3500/94M VGA Display Unit; do not present those values as independently measured bare-190214-01 ratings. |
| Complete-system Approvals | Hazardous-area approval statements apply only to the complete matched configuration and selected approval option, not automatically to bare 190214-01. |
Compatibility statements are limited to the cited manufacturer documentation. Availability, condition and substitution must be confirmed separately.
Bently Nevada 190214-01 is the 3500/94M Normal I/O module listed as an exact spare in Baker Hughes datasheet 122M3217 Rev. N.
Bently Nevada 190214-01 is not the front main module; 190214-01 is the rear Normal I/O module associated with a 3500/94M VGA display path.
Bently Nevada 190214-01 is not a complete VGA display system because 190214-01 requires the matched front module, display, cables, rack, 3500/22 TDI, and configuration.
Bently Nevada 190214-01 occupies one full-height rear slot in a compatible 3500 rack.
Bently Nevada 190214-01 uses the official I/O-module envelope of 241.3 x 24.4 x 99.1 mm and weighs 0.34 kg (0.75 lb).
Bently Nevada 190214-01 is the Normal I/O module, while 190214-02 is the separately listed power-only I/O module for the front-mount display option.
A complete matched 3500/94M path using Bently Nevada 190214-01 can present rack events, alarms, module and channel data, status, and configured custom screens; 190214-01 alone does not perform the complete display function.
A hazardous-area approval cannot be assumed for bare Bently Nevada 190214-01 without the complete configured order option and applicable certification evidence for 190214-01.
Send the complete part number, installed-system details, quantity, destination and clear label photos. Availability and condition will be confirmed before quotation.
