3500/46M
3500/46M identifies the Bently Nevada four-channel Hydro Monitor model family. 3500/46M supports configured hydro-machine measurements using compatible proximity, seismic, dynamic-pressure, and air-gap sensors, including vibration, position, static pressure, and dynamic pressure functions. The official order-code root is 3500/46-AA-BB. This record does not select any of the six AA I/O-module types or a BB approval option and does not assign an exact main-module or I/O spare part number. Baker Hughes states that the Hydro Velocity channel type must not be used for automated machinery protection.
Scope note: 3500/46M does not select an I/O or output option, approval suffix, exact front-module spare, or exact rear-module spare. Content must remain at model/family level until an exact order code or nameplate is available.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales1@amikon.cnWhatsapp/Mob:
+86 18150117685Official model-family information only; no unlisted order variant or exact spare part number is assigned.
3500/46M is verified as the displayed model or manufacturer ordering-family identity in Baker Hughes / Bently Nevada document 144408 Rev. AD.
The manufacturer describes the 3500/46M as a four-channel hydro-machine monitor for configured vibration, air-gap, position, acceleration, and pressure measurements.
3500/46M does not select an I/O or output option, approval suffix, exact front-module spare, or exact rear-module spare. Content must remain at model/family level until an exact order code or nameplate is available.
| Manufacturer | Baker Hughes / Bently Nevada |
|---|---|
| Displayed model | 3500/46M |
| Official datasheet family | 3500/46M Hydro Monitor |
| Identity level | Model and ordering family only; no exact SKU assigned |
| Official ordering pattern | 3500/46-AA-BB |
| Selected I/O or output option | Not specified by the inventory record |
| Selected approval option | Not specified by the inventory record |
| Channel count | 4 |
| Input count | 1 to 4 compatible sensor signals |
| Supported sensor families | Proximity, seismic, dynamic-pressure, and air-gap sensors, depending on selected I/O and channel type |
| Typical power consumption | 7.7 W |
| Published measurement families | Hydro radial vibration, air gap, velocity, acceleration, thrust, multimode pressure, and stator end-winding functions |
| Multimode capability | Up to eight configured alarm-parameter sets per multimode channel |
| Available I/O categories | Six internal/external standard or multimode I/O choices; no category selected by this record |
| Hydro Velocity limitation | Hydro Velocity channel type is not for automated machinery protection |
| Rack space | One full-height front slot plus one compatible full-height rear I/O slot |
| Main-board dimensions | 241.3 x 24.4 x 241.8 mm |
| Main-board weight | 0.91 kg |
| Official source | 144408 Rev. AD |
| Configured-system Required integration | 3500/46M requires the I/O type matched to the selected hydro sensor and measurement function, a compatible 3500 rack, applicable termination hardware, and software configuration. |
| Configured-system Performance scope | 3500/46M sensor compatibility, signal sensitivity, multimode behavior, recorder outputs, and approvals depend on the selected I/O, channel type, firmware, and installed configuration. |
| Configured-system Functional boundary | 3500/46M does not identify an exact monitor spare, I/O type, sensor package, multimode configuration, approval suffix, or complete hydro-protection system; Hydro Velocity is not for automated protection. |
| Configured-system Approval boundary | 3500/46M has no selected approval suffix in this record. Any approval claim requires the exact ordered variant, applicable certificate, installation drawing, and installed configuration. |
Compatibility statements are limited to the cited manufacturer documentation. Availability, condition and substitution must be confirmed separately.
3500/46M is the Bently Nevada four-channel Hydro Monitor model family for configured hydro-machine measurements.
3500/46M provides four channels for compatible selected hydro-machine sensor and measurement functions.
3500/46M can use compatible proximity, seismic, dynamic-pressure, and air-gap sensors when 3500/46M uses the matching I/O and channel configuration.
3500/46M supports configured hydro radial-vibration, air-gap, velocity, acceleration, thrust, pressure, and stator end-winding functions.
3500/46M has a manufacturer-published typical power consumption of 7.7 W.
3500/46M Hydro Velocity must not be used for automated machinery protection because Baker Hughes identifies that 3500/46M channel type as an early-warning and diagnostic function.
3500/46M does not specify an AA I/O-module option or BB approval option in the official 3500/46-AA-BB ordering pattern.
3500/46M does not identify an exact spare part number; 3500/46M is published here only at model and family level.
Send the complete part number, installed-system details, quantity, destination and clear label photos. Availability and condition will be confirmed before quotation.
