5205-DFNT-PDPS
EtherNet/IP to PROFIBUS DP Slave Gateway · Stand-alone gateway linking EtherNet/IP client or server messaging to a PROFIBUS DP-V0 slave interface.
Lifecycle note: Use the unit nameplate and current official documentation as final references before approving a replacement.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales17@amikon.cnWhatsapp/Mob:
+86 15359408275EtherNet/IP to PROFIBUS DP Slave Gateway · ProSoft ProLinx 5000 Series
ProSoft 5205-DFNT-PDPS is a stand-alone ProLinx gateway that links EtherNet/IP explicit messaging to a PROFIBUS DP-V0 slave connection.
The module provides one Ethernet port, one configurable PROFIBUS DB9F port, user-defined register mapping and up to 244 bytes of input and output data within the documented 400-byte total limit.
Before replacement, export the configuration and record the PROFIBUS address, baud and GSD file, byte mapping and swap rules, EtherNet/IP client commands and server use, IP settings, failure behavior and 24 VDC wiring.
| Manufacturer | ProSoft Technology |
|---|---|
| Model | 5205-DFNT-PDPS |
| Product family | ProLinx 5000 Series |
| Ethernet protocol | EtherNet/IP explicit messaging client and server |
| PROFIBUS role | DP-V0 slave |
| Ethernet port | One RJ45 |
| PROFIBUS port | One configurable DB9F |
| PROFIBUS rate | 9.6 kbit/s to 12 Mbit/s |
| PROFIBUS address | 1 to 125 |
| PROFIBUS I/O | 244 input bytes and 244 output bytes; 400 bytes total |
| EtherNet/IP client commands | Up to 100 |
| Server sockets | Five independent TCP server sockets |
| Power supply | 24 VDC nominal; 18-36 VDC |
| Current load | 500 mA maximum at 24 VDC |
| Operating temperature | -20 to +50 deg C |
| Mounting | DIN rail |
ProSoft 5205-DFNT-PDPS exchanges mapped process data between EtherNet/IP explicit messaging and a PROFIBUS DP-V0 master through its slave interface.
ProSoft 5205-DFNT-PDPS can operate as an explicit-messaging client and server, with the configured command list and internal database controlling data transfer.
ProSoft 5205-DFNT-PDPS supports up to 244 input bytes and 244 output bytes with a documented combined limit of 400 bytes.
Preserve the node address, GSD file, baud negotiation, input and output sizes, byte swapping and loss-of-connection behavior from ProSoft 5205-DFNT-PDPS.
A generic gateway cannot replace ProSoft 5205-DFNT-PDPS unless it supports the same EtherNet/IP roles, PROFIBUS slave function, data sizes, mapping and failure behavior.
Commission ProSoft 5205-DFNT-PDPS by checking 24 VDC power, Ethernet addressing, every configured client command, PROFIBUS cyclic data, byte order, diagnostics and communication-loss responses.
Provide the full ProSoft 5205-DFNT-PDPS nameplate, firmware, exported configuration, network and GSD details, quantity and destination.
Send the complete 5205-DFNT-PDPS catalog number, revision, quantity, destination and nameplate photo. Identification details will be checked before quotation.
