SDCS-PIN-4B 3ADT316300R1510
Interface board for DCS800-S DC converter modules, covering low-voltage supplies, armature firing and measurement, and configuration-dependent field functions. Confirm the exact installed configuration and revision before replacement.
Scope note: Supplied as a model-specific industrial component; system engineering, accessories and site acceptance are verified separately.
Product Condition
Original New with One Year WarrantyParts Available
In Stock and Same Day ShippingDelivery Mode
Shipping via DHL Fedex or UPS etcEmail:
sales1@amikon.cnWhatsapp/Mob:
+86 18150117685DCS800 interface board for DCS800
This ABB DCS800 interface board supports D1 through D4+ converter modules across the published 20 A to 1190 A range and is used in both two-quadrant and four-quadrant configurations.
Its onboard field-control function applies to D1 through D4 assemblies, while the D4+ 1190 A spare-parts listing identifies the same order code without field supply, so the complete drive frame and field arrangement must be verified before ordering.
Ordering note: Verify the complete model, installed system, revision and current manufacturer documentation before purchase or installation.
| Manufacturer | ABB |
|---|---|
| Board designation / order code | SDCS-PIN-4b / 3ADT316300R1510 |
| Drive family | DCS800-S DC converter modules |
| Compatible frame / current range | D1 to D4+; 20 A to 1190 A |
| Supported converter configurations | 2-Q and 4-Q |
| Mains application range | 230 VAC to 525 VAC and 600 VAC |
| Auxiliary supply selection | Automatically adapts to 115 VAC or 230 VAC |
| Functional coverage | Small-voltage supply and armature firing/measurement for D1–D4+; onboard field control and measurement for D1–D4 |
Compatibility depends on the complete ordering code, installed hardware, wiring and approved engineering data.
It is specified for D1 through D4+ converter modules covering the 20 A to 1190 A range.
The board automatically adapts to either 115 VAC or 230 VAC auxiliary power.
It supplies the drive’s small voltages, controls armature firing and measurement, interfaces with armature-current sensing, and manages the applicable onboard field circuit.
ABB lists the current board as the replacement for the preceding interface-board design in common D1 through D4 assemblies, subject to verification of the complete drive configuration.
A qualified technician should verify the complete drive designation, frame size, voltage, quadrant configuration, field-supply arrangement, connector layout, and safe isolation state before fitting the board.
